Switch HikVision DS-3E3754TF, 24 porturi Gigabit RJ45, 24 porturi SFP Gigabit, 6 porturi SFP+ 10G, rutare avansata OSPF/BGP/MPLS, VLAN 802.1Q, MACsec, QoS, SNMP, management Web si SSH
Descriere
- General
- ShellIron shell, fan cooling design
- Net Weight5.5 kg (12.13 lb)
- Dimensions (W × H × D)440.00 mm × 44.00 mm × 350.00 mm (17.32'' × 1.73'' × 13.78'')
- Operating Temperature0 °C to 50 °C (32 °F to 122 °F)
- Storage Temperature-20 °C to 70 °C (-4 °F to 158 °F)
- Operating Humidity10% to 90% (no condensation)
- Relative Humidity5% to 95% (no condensation)
- Power Consumption in Idle75 W
- Network Parameters
- Ports24 × 1 Gigabit RJ45 port,24 × 1 Gigabit fiber optical port,6 × 10 Gigabit fiber optical port
- Forwarding ModeStore-and-forward switching
- MAC Address Table32 K
- Switching Capacity
Whole-Device Performance: 598 Gbps
Port Performance: 598 Gbps
- Packet Forwarding Rate
Whole-Device Performance: 252 Mpps
Port Performance: 252 Mpps
- Software Function
- Device Maintenance
Support Console, Telnet, SSH
Support web, http, https
Support FTP, TFTP, Xmodem, SFTP
Support SNMP V1/V2c/V3
Support RMON
Support NTP
- Reliability
Support STP/RSTP/MSTP
Support EAPS/MEAPS
Support MRD-Ring
Support ERPS
Support VRRP
Support BFD for OSPF
Support BFD for BGP
- VLAN
Support IEEE 802.1Q (VLAN), 4096 VLAN IDs
Support GVRP
Support QinQ
Support VLAN based on MAC/protocol/IP subnet/policy/port
Support Private VLAN
Support 1:1 and N:1 VLAN mapping functions
- Port Mirroring
Support local and remote port mirroring
Support N:4 port mirroring
Support flow mirroring
Support MAC mirroring
- Routing Feature
Support static routing, RIP, OSPF, BGP, MPLS
Support IPv4/IPv6 ECMP
Support VRRP, VRRP v3
Support IPv4/IPv6 policy-based routing
Support IPv4/IPv6 routing policy
Support IPv4/IPv6 dual stack
Support IPv6 static routing, RIPng, OSPFv3
- QoS
Support Diff-Serv QoS
Support 802.1p/DSCP priority mapping
Support queue scheduling including SP, WRR, WFQ, SP+WRR, SP+WFQ
Support priority marking and remarking
Support traffic shaping
Support congestion avoidance, Tail-Drop and WRED
Support 802.1p, TOS, DSCP, and EXP priority mapping
Support port/flow-based rate limiting
- Multicast
Support IGMP v1/v2/v3 Snooping
Support IGMP V1/V2/V3
Support MLD Snooping v1/v2
Support MLD v1/v2
- ACL
Support IP-based ACL/MAC-based ACL
Support based on MAC Address, IP Address, Ethertype, Protocol Type, VLAN ID, DSCP, 802.1p Priority
Support up to 256 ACLs
- Link AggregationSupport IEEE 802.3ad LACP/static link aggregation
- Security
Support AAA,TACACS+ Radius authentication
Support 802.1X authentication, MAC authentication, MAC bypass authentication
Support to prevent DOS, ARP attack function, ICMP anti attack
Support binding of IP, MAC, port and VLAN
Support MAC authentication
Support MAC address filtering
Support broadcast/multicast/unknown-unicast storm control
