Descriere
- Key Feature
- Link AggregationSupport static link aggregation with up to 2 aggregation groups and up to 4 ports in each group.
- Network Parameters
- Port Number8 × gigabit RJ45 ports
- Port TypeRJ45 port, full duplex, MDI/MDI-X adaptive
- Working ModeStandard mode (default)
- StandardIEEE 802.3, IEEE 802.3u, IEEE 802.3x, and IEEE 802.3ab
- Forwarding ModeStore-and-forward switching
- MAC Address Table4 K
- Internal Cache1.5 Mbits
- Switching Capacity16 Gbps
- Packet Forwarding Rate11.904 Mpps
- Operation Management
- Device MaintenanceSupport remote upgrade, recovering default parameters, viewing logs, configuring basic network parameters.
- Port ConfigurationSupport rate, flow control, and switch configuration
- General
- Dimension (W × H × D)170 mm × 27.6 mm × 93.1 mm (6.69” × 1.09” × 3.67”)
- Storage Temperature-40°C to 85°C (-40°F to 185°F)
- Power Source5 W
- Gross Weight0.36 kg (0.79 lb)
- Power Consumption In Idle5 W
- ShellMetal material, fan-free design
- Operating Temperature0°C to 40°C (32°F to 104°F)
- Operating Humidity5% to 95% (no condensation)
- Power Supply5 VDC, 1 A
- Max. Power Consumption5 W
- Relative Humidity5% to 95% (no condensation)
Detalii produs
Cod produs - SKU
DS-3E1508-EI
Categorie
Greutate produs
0.75 kg.
Producator
Fisa tehnica
