NOU
Switch HikVision 20 porturi PoE Gigabit , 4 porturi HiPoE Gigabit si un doua porturi Gigabit fibra optica DS-3E0528HP-E
2.123,47 RON
(TVA inclus)
Costurile de livrare nu sunt incluse
Cum te putem ajuta?
Descriere
Switch 24 porturi PoE Hikvision DS-3E0528HP-E
Power over Ethernet – PoE
Reprezinta modalitatea de alimentare a camerelor sau a altor echipamente IP, prin intermediul cablului de retea. Implementarea retelei se rezuma la un singur cablu, prin care este transmis semnalul de date cat si alimentarea echipamentului. Prin intermediul PoE, instalarea sistemelor de supraveghere devine mult mai simpla, mai sigura si mai putin costisitoare.
- PoE Power Supply
- PoE Standard
Ports 1 to 4: IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt
Ports 5 to 24: IEEE 802.3af, IEEE 802.3at
- PoE Power Pin
Ports 5 to 20: Ethernet cables 1/2/3/6 provide power supply.
Ports 1 to 4 and 21 to 24: Ethernet cables 1/2/3/6 and 4/5/7/8 provide power supply simultaneously.
- PoE PortPorts 1 to 24
- Max. Port Power
Ports 1 to 4: 90 W
Ports 5 to 24: 30 W
- Hi-PoE PortPorts 1 to 4
- PoE Power Budget370 W
- Network Parameters
- Port Number20 × gigabit PoE ports, 4 × gigabit Hi-PoE ports, 2 × gigabit RJ45 ports, and 2 × gigabit fiber optical ports
- Port TypeRJ45 port, full duplex, MDI/MDI-X adaptive
- StandardIEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, and IEEE 802.3z
- Forwarding ModeStore-and-forward switching
- Working ModeStandard mode (default), Extend mode, Isolation mode, PoE watchdog mode
- Ports For Long-Distance TransmissionPorts 21 to 24
- MAC Address Table8 K
- Switching Capacity56 Gbps
- Packet Forwarding Rate41.664 Mpps
- Internal Cache4.1 Mbits
- Dialing Function
- Long RangePorts 21 to 24: up to 300 m; and the speed rate of the port is 10 Mbps.
- Port IsolationPorts 1 to 24: port isolation mode to improve network security.
- PoE WatchdogPorts 1 to 24: auto detect and restart the cameras that do not respond.
- General
- ShellMetal material
- Net Weight2.98 kg (6.57 lb)
- Dimension (L × H × D)440 mm × 220.8 mm × 44 mm (17.32” × 8.69” × 1.73”)
- Operating Temperature-10 °C to 55 °C (14 °F to 131 °F)
- Storage Temperature-40 °C to 85 °C (-40 °F to 185 °F)
- Operating Humidity5% to 95% (no condensation)
- Storage Humidity5% to 95% (no condensation)
- Power Supply100 to 240 VAC, 50/60Hz, Max. 6.5 A
- Power Consumption In Idle< 30 W
- Power Souce400 W
- Max. Power Consumption400 W
- Approval
- EMCFCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 55024: 2010 +A1: 2015); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016)
- SafetyUL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013)
- ChemistryCE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
Detalii
SKU
DS-3E0528HP-E
EAN
6941264031635
Categorii
Greutate
0.75 kg
Brand
Producator
Hikvision
PoE
Da
Numar porturi
24
