Switch de retea PoE Hikvision DS-3E0109P-E/M(C) unmanaged cu 8 porturi 10/100 Mbps PoE + 1 port uplink 10/100 Mbps, intelligent PoE management, transmisie PoE pana la 300 m, 8‑core adaptive power, protectie 6 kV si port VIP

HikVision
204,51 RON (TVA inclus)
169,02 RON (fara TVA)
HikVision
Cumpara de minim 500 lei pentru transport gratuit
Stoc 82
Cod produs - SKU DS-3E0109P-E/M(C)
EAN 8649
Disponibil in stoc
Adauga la Favorite
Cum te putem ajuta?
Suna-ne: 0761.40.40.40 (Luni - Vineri: 08:30 - 17:30)
Trimite-ne un mesaj

Descriere

Switch 8 porturi PoE Hikvision carcasa metalica DS-3E0109P-E/M(B)



Power over Ethernet – PoE

Reprezinta modalitatea de alimentare a camerelor sau a altor echipamente IP, prin intermediul cablului de retea. Implementarea retelei se rezuma la un singur cablu, prin care este transmis semnalul de date cat si alimentarea echipamentului. Prin intermediul PoE, instalarea sistemelor de supraveghere devine mult mai simpla, mai sigura si mai putin costisitoare.



  • Network Parameters
  • Port Number8 × 100 Mbps PoE ports, 1 × 100 Mbps Ethernet port
  • Port TypeRJ45 port, full duplex, MDI/MDI-X adaptive
  • StandardIEEE 802.3, IEEE 802.3u, IEEE 802.3x
  • Forwarding ModeStore-and-forward switching
  • Working ModeStandard mode (default); Extend mode
  • High Priority PortsPorts 1 to 2
  • Ports For Long-Distance TransmissionPorts 1 to 8
  • MAC Address Table2 K
  • Switching Capacity1.8 Gbps
  • Packet Forwarding Rate1.339 Mpps
  • Internal Cache1 Mbits
  • PoE Power Supply
  • PoE StandardIEEE 802.3af, IEEE 802.3at
  • PoE Power PinSupports 8-core power supply, Ethernet cable 1/2/3/6 and 4/5/7/8 provide simultaneous power supply
  • PoE PortPorts 1 to 8
  • Max. Port Power30 W
  • PoE Power Pudget60 W
  • Max. Power Consumption65 W
  • General
  • ShellMetal material, fan-free design
  • Gross Weight0.89 kg (1.96 lb)
  • Net Weight0.35 kg (0.77 lb)
  • Dimension (L × H × D)170 mm × 27.6 mm × 93.1 mm (6.7” × 1.1” × 3.7”)
  • Operating Temperature-10 °C to 55 °C (14 °F to 131 °F)
  • Storage Temperature-40 °C to 85 °C (-40 °F to 185 °F)
  • Operating Humidity5% to 95% (no condensation)
  • Storage Humidity5% to 95% (no condensation)
  • Power Supply48 VDC, 1.35 A
  • Power Consumption In Idle5 W
  • Approval
  • EMCFCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 55024: 2010 +A1: 2015); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016)
  • SafetyUL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013)
  • ChemistryCE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)

Detalii

SKU
DS-3E0109P-E/M(C)
EAN
8649
Categorii
Switch PoE
Greutate
2 kg
Brand
HikVision
Producator
HikVision
Numar porturi
8
Fisa tehnica
DS-3E0109P-E_MC_Datasheet_20250110.pdf
