DVR Hikvision 8 canale AcuSense cu alarma 5MP iDS-7208HUHI-M1/X/4A+8/4ALM

Descriere

H.265 Pro+

H.265+ imbunatateste dramatic eficienta codificarii: reducerea cerintelor privind latimea de banda cu pana la 75% fata de H.2645 si ocuparea a jumatate din spatiul de stocare pentru acelasi numar de inregistrari video. H.265+ reprezinta un pas important in compresia video si inseamna economii semnificative ale costurilor de stocare pentru utilizatori.

Functia  AcuSense filtreaza si elimina alarmele false (pasari, frunze, ploaie, lumina) cu o acuratete de peste 90%.

Modalitatea foarte usoara de configurare a echipamentului permite vizualizarea chiar si de la distanta a camerelor. Aplicatia Hik-Connect va pune la dispozitie, printr-o simpla scanare a codului QR posibilitatea de a monitoriza zona dorita, oricand si oriunde

Monitorizarea de la distanta

Ofera posibilitatea de a urmari locuita personala sau spatiul comercial de la distanta, prin intermediul unui smartphone, tableta sau laptop.   Aceasta este o solutie optima, pentru a vedea transmisia sistemului video de supraveghere detinut intr-o anumita locatie cu ajutorul unei conexiuni la internet, 3G sau 4G.

• • Facial Recognition
  • Face Picture Library

    Up to 16 face picture libraries;

    HDD damage will not cause data loss in the face picture library, because the library has been backed up by HDD and flash.

  • Face Picture Comparison4-ch face picture comparison alarm (HD analog camera)
  • Perimeter Protection
  • Human/Vehicle AnalysisUp to 8-ch (advanced model)
  • Facial Detection
  • Facial Detection and Capture

    Face picture detection, face picture search；

    4-ch face picture capture

  • Video and Audio
  • IP Video Input

    8-ch (up to 16-ch), each up to 4 Mbps

    Support H.265+/H.265/H.264+/H.264 IP cameras

  • Analog Video Input

    8-ch

    BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection

  • HDMI Output

    1-ch, 4K (3840 × 2160)/30Hz,

    2K (2560 × 1440)/60Hz,

    1920 × 1080/60Hz,

    1280 × 1024/60Hz,

    1280 × 720/60Hz

    HDMI/VGA simultaneous output

  • VGA Output

    1-ch, 1920 × 1080/60Hz,

    1280 × 1024/60Hz,

    1280 × 720/60Hz

    HDMI/VGA simultaneous output

  • CVBS InputPAL/NTSC
  • CVBS Output

    1-ch, BNC (1.0 Vp-p, 75 Ω),

    resolution: PAL: 704 × 576, NTSC: 704 × 480

  • Synchronous Playback8-ch
  • HDTVI Input8 MP(3840 × 2160)@12/15 fps, 3K(2960 x 1665)@25/20 fps,3K(3328x1504)@20fps,5 MP(2560 × 1944)@20 fps, 4 MP(2560 × 1440)@25/30 fps,1080P@25/30 fps, 720P@25/30fps
  • AHD Input5 MP(2560 × 1944)@20 fps, 4 MP(2560 × 1440)@25/30 fps,1080P@25/30 fps, 720P@25/30fps
  • HDCVI Input8 MP(3840 × 2160)@12/15 fps, 3K(2880×1620)@25fps, 5 MP(2592 × 1944)@20 fps, 4 MP(2560 × 1440)@25/30 fps,1080P@25/30 fps, 720P@25/30fps
  • Audio Output1-ch, RCA (Linear, 1 KΩ)
  • Audio Input1-ch(up to 8-ch is optional), RCA (2.0 Vp-p, 1 KΩ), 8-ch via coaxial cable
  • Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input)
  • Recording
  • Video CompressionH.265 Pro+/H.265 Pro/H.265/H.264+/H.264
  • Encoding Resolution8 MP/5 MP/3K/4 MP/3 MP/1080p/720p/WD1/4CIF/VGA/CIF
  • Frame Rate

    Main stream:

    8 MP@8 fps/3K@12 fps/5 MP@12 fps/4 MP@15 fps/8 MP Lite@15 fps/1080p/720p@25 fps (P)/30 fps (N)

    Sub-stream:

    WD1/4CIF/CIF@25 fps (P)/30 fps (N)

  • Video Bitrate32 Kbps to 10 Mbps
  • Dual-streamSupport main stream or sub stream
  • Stream TypeVideo, Video & Audio
  • Audio CompressionG.711u
  • Audio Bitrate64 Kbps
  • Decoding
  • Decoding Capabilityup to 24-ch 1080P@30fps
  • Network
  • Total Bandwidth256 Mbps
  • Network ProtocolTCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF, ISUP
  • Remote Connection64
  • Network Interface1, RJ45 10M/100M/1000M self-adaptive Ethernet interface
  • Auxiliary Interface
  • SATA1 SATA interface
  • Capacityup to 12 TB capacity for each disk
  • Serial InterfaceRS-485 (half-duplex)
  • USB Interface

    Front panel: 1 × USB 2.0;

    Rear panel: 1 × USB 3.0

  • Alarm In/OutN/A (optional to support)
  • General
  • Power Supply12 VDC, 2 A
  • Consumption≤ 10 W (without HDD)
  • Working Temperature-10 °C to 55 °C (14 °F to 131 °F)
  • Working Humidity10% to 90%
  • Dimension (W × D × H)319 × 240 × 48 mm (12.6 × 9.4 × 1.9 inch)
  • Weight≤ 2 kg (4.4 lb)
