Camera supraveghere turret 5MP, Network, TP-Link VIGI C485(2.8MM)

Descriere

Specifications
Camera
Product Model VIGI C485(2.8mm/4mm)
Image Sensor 1/2.7“ Progressive Scan CMOS
Min. Illumination 0.005 Lux; 0 Lux with IR/White Light
Shutter Speed 1/3 to 1/10000 s
Slow Shutter Yes
Day & Night Mechanism IR Cut Filter
Day/Night Switch Unified/Scheduled/Auto
Lens
Type Fixed Focal Lens
Focal Length
4 mm
2. 8mm
Aperture F1.6
FOV
• 2.8 mm:
Horizontal FOV: 111.4°, Vertical FOV: 58.8°, Diagonal FOV: 134°
• 4 mm:
Horizontal FOV: 91.5°, Vertical FOV: 46.1°, Diagonal FOV: 109.6°
Lens Mount M12*P 0.5
DORI Distance
• 2.8 mm
Detect: 85 m (278 ft)
Observe: 35 m (116 ft)
Recognize: 17 m (56 ft)
Identify: 8 m (28 ft)
• 4 mm
Detect: 107 m (350 ft)
Observe: 44 m (146 ft)
Recognize: 21 m (70 ft)
Identify: 11 m (35 ft)
Angle Adjustment (manual)
Range Pan: 0° to 360°, Tilt: 0° to 85°, Rotation: 0° to 360°
Illuminator
IR LED
Quantity: 4
Range: 30m
Wavelength: 850nm
White LED Quantity: 4
Range: 30m
Illuminator On/Off Control Auto/Scheduled/Always on/Always off
Video
Max. Resolution 3840 X 2160
Main Stream
• Frame Rate
50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
• Resolution:
3840x2160, 2560x1440, 2304x1296, 2048x1280, 1920x1080,
1280x720
• Note:
If the image rotation is set to 90° or 270°, the frame rate only
supports up to 20fps.
If 120dB is turned on, the frame rate can only support up to 20fps.
Sub-Stream
• Frame Rate
50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
• Resolution:
848x480, 704x576, 640x480, 640x360, 352x288, 320x240
• Note:
If the image rotation is set to 90° or 270°, the frame rate only
supports up to 20fps.
If 120dB is turned on, the frame rate can only support up to 20fps.
Bit Rate Control CBR, VBR
Video Compression Main stream: H.265/H.265+/H.264/H.264+
Sub-stream: H.265/H.264
H.264 Type High Profile
H.264+ Main Stream Supported
H.265 Type Main Profile*
H.265+ Main Stream Supported*
Video Bit Rate • Main Stream: 256 Kbps to 8 Mbps
• Sub-Stream: 64 Kbps to 512 Kbps
Image Settings
Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure,
WDR, White Balance, Prevent Overexposure to Infrared Light, HLC
Adjustable by Client Software
Day/Night Switch Unified, Scheduled, Auto
Image Enhancement BLC/3D DNR/HLC/SmartIR
Wide Dynamic Range (WDR)
120dB
Note: When People & Vehicle Analytics is enabled, only DWDR is
supported.
SNR ≥ 52 dB
Image Parameters Switch Yes
Privacy Mask Up to 4 Masks
ROI 1 Region
OSD Setting Yes
Audio
Audio Communication Two-way audio
Audio Input Yes
Audio Output Yes
Audio Compression Yes
Audio Sampling Rate 8KHz
Environment Noise Filtering Yes
Audio Bit Rate 64 Kbps(G.711 alaw)
Network
Protocols TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP,
SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP
API Open Network Video Interface (Profile S)
Web Browser
Google Chrome® 57 and above
Firefox® 52 and above
Safari® 11 and above
Microsoft® Edge 91 and above
Security Password Protection, HTTPS Encryption, IP Address Filter, Digest
Authentication
Simultaneous Live View 3 Main Streams & 3 Sub-Streams
Client VIGI App, VIGI Security Manager, VIGI NVR, Web,VMS
Cloud Yes
ONVIF Yes
Interface
Network Interface 1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE
On-board Storage Built-In Memory Card Slot, Support MicroSD Card, up to 512 GB**
Built-in Speaker Yes
Built-in Microphone Yes; Records Anything Going on within a 15-ft Radius of the Camera
Audio N/A
Alarm N/A
Reset Button Yes
Power DC Power Port
Alarm and Event Management
Smart Event
• Human & Vehicle Classification
• Intrusion Detection
• Line-Crossing Detection
• Region Entering Detection
• Region Exiting Detection
• Object Abandoned Detection
• Object Removal Detection
• Loitering Detection
• People Detection
• Vehicle Detection
• Abnormal Sound Detection
• Scene Change Detection
Basic Event
• Motion Detection
• Video Tampering Detection
• Exception ( Illegal Login)
Alarm Linkage
• Memory Card Video Recording
• Message Push
• Audible Warning
• White Light Flashing
Linkage Method N/A
Output Notification Message Push
Deep Learning Function
People & Vehicle Analytics Search and filter to people or vehicle of interest based on many
different attributes, making post-event search faster and easier.
General
Operating Temperature -30–60 °C
Storage Temperature -40–60 °C
Operating Humidity 95% or Less (Non-condensing)
Storage Humidity 95% or Less (Non-condensing)
Power Supply 12V DC ± 5%, Max. 11.5 W, 5.5 mm Coaxial Power Plug
PoE: 802.3af/at, class 0, Max. 12.5 W
Material Metal
Protection IP67
Product Dimensions (L x W x H) 111*111*83.7mm
Package Contents
VIGI Network Camera
Quick Start Guide
Waterproof Cable Attachments
Mounting Accessories
Net Weight 0.48 Kg
Certifications CE, NTRA, VCCI, KC, BSMI, FCC, IC
