Camera supraveghere bullet 4MP, Network, TP-Link VIGI C340I(2.8MM)

Descriere

Specifications
Camera
Product Model VIGI C320I VIGI C330I VIGI C340I
Image Sensor 1/3” Progressive Scan
CMOS
1/2.8” Progressive Scan
CMOS
1/3” Progressive Scan
CMOS
Slow Shutter Yes
Min. Illumination Color: 0.01 Lux; 0 Lux with IR
Day & Night Mechanism IR Cut Filter
Day/Night Switch Unified/ Scheduled/ Auto
Lens
Focal length 2.8 mm/4 mm/6 mm 2.8 mm/4 mm/6 mm 2.8 mm/4 mm/6 mm
Aperture
2.8mm: F2. 2
4mm: F2.0
6mm: F2.0
2.8mm: F2.2
4mm: F2.0
6mm: F2.0
2.8mm: F2.2
4mm: F2.0
6mm: F2.0
Focus Fixed
FOV
2.8mm: 88.2°/48.6°/106.5°
(H/V/D)
4mm: 75.2/40.8°/88.3°
(H/V/D)
6mm: 49.8°/27.6°/57.7°
(H/V/D)
2.8mm: 97.8°/52.9°/117.9°
(H/V/D)
4mm: 82.8°/44.5°/98.1°
(H/V/D)
6mm: 54.5°/30.0°/63.2°
(H/V/D)
2.8mm: 88.8°/48.9°/106.5°
(H/V/D)
4mm: 75.2°/40.8°/88.3°
(H/V/D)
6mm: 49.8°/27.6°/57.7°
(H/V/D)
Lens Mount M12 M12 M12
DORI Distance
2.8 mm:
Detect: 45 m (149 ft)
Observe:19 m (62 ft)
Recognize: 9 m (30 ft)
Identify: 5 m (15 ft)
4 mm:
Detect: 60 m (198 ft)
Observe: 25 m (83 ft)
Recognize: 12 m (40 ft)
Identify: 6 m (20 ft)
6 mm:
Detect: 91 m (297 ft)
Observe: 38 m (124 ft)
Recognize: 18 m (59 ft)
Identify: 9 m (30 ft)
2.8 mm:
Detect: 49 m (161 ft)
Observe: 20 m (67 ft)
Recognize: 10 m (32 ft)
Identify: 5 m (16 ft)
4 mm:
Detect: 65 m (214 ft)
Observe: 27 m (89 ft)
Recognize: 13 m (43 ft)
Identify: 7 m (21 ft)
6 mm:
Detect: 98 m (321 ft)
Observe: 41 m (134 ft)
Recognize: 20 m (64 ft)
Identify: 10 m (32 ft)
2.8 mm:
Detect: 60 m (197 ft)
Observe: 25 m (82 ft)
Recognize: 12 m (39 ft)
Identify: 6 m (20 ft)
4 mm:
Detect: 80 m (262 ft)
Observe: 33 m (109 ft)
Recognize: 16 m (52 ft)
Identify: 8 m (26 ft)
6 mm:
Detect: 120 m (394 ft)
Observe: 50 m (164 ft)
Recognize: 24 m (79 ft)
Identify: 12 m (39 ft)
Angle Adjustment (Manual)
Range
• Pan: 0° to 360°
• Tilt: 0° to 90°
• Rotation: 0° to 360°
Illuminator
IR LED
• Quantity: 2
• Range: 50m
• Wavelength: 850nm
White LED N/A
Illuminator On/Off
Control Auto/Scheduled/Always on/Always off
Video
Max. Resolution 2MP (1920 × 1080) 3MP (2304 × 1296) 4MP (2560 × 1440)
Main Stream
Frame Rate: 1fps, 5fps,
10fps, 15fps, 20fps, 25fps,
30fps
Resolution: 1920x1080,
1280x960, 1280x720
Frame Rate: 1fps, 5fps,
10fps, 15fps, 20fps, 25fps,
30fps
Resolution: 2304x1296,
2048x1280, 1920x1080,
1280x720
Frame Rate: 1fps, 5fps,
10fps, 15fps, 20fps, 25fps,
30fps
Resolution:
2560x1440,2304x1296,
2048x1280, 1920x1080,
1280x720
Sub-Stream
Frame Rate: 1fps, 5fps,
10fps, 15fps, 20fps, 25fps,
30fps
Resolution: 704x576,
640x480, 352x288,
320x240
Frame Rate: 1fps, 5fps,
10fps, 15fps, 20fps, 25fps,
30fps
Resolution: 704x576,
640x480, 352x288,
320x240
Frame Rate: 1fps, 5fps,
10fps, 15fps, 20fps, 25fps,
30fps
Resolution: 640x480,
352x288, 320x240
Bit Rate Control CBR, VBR
Video Compression
• Main Stream: H.265+/H.265/H.264+/H.264
• Sub-Stream: H.265/H.264
H.264 Type High Profile
H.264+ Main Stream Supported
H.265 Type Main Profile
H.265+ Main Stream Supported
Video Bit Rate • Main Stream: 256 Kbps to 4 Mbps
• Sub-Stream: 64 Kbps to 512 Kbps
Image Settings
• Mirror
• Brightness
• Contrast
• Saturation
• Sharpness
• Exposure
• WDR
• White Balance
• Prevent Overexposure to Infrared Light
• HLC Adjustable by Client Software
• Rotation(90°/270°)
Image Enhancement BLC/3D DNR/HLC/SmartIR
Wide Dynamic Range DWDR
SNR ≥ 52 dB
Image Parameters
Switch Yes
Privacy Mask Up to 4 Masks
ROI 1 Region
OSD Setting Yes
Audio
Audio Communication N/A
Audio Input Yes
Audio Output N/A
Audio Compression Yes
Audio Sampling Rate 8KHz
Environment Noise
Filtering Yes
Audio Bit Rate 64 Kbps(G.711 alaw)
Network
Protocols TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP, SSL/TLS, FTP/SFTP,
RTP, IPv4, IPv6 (VIGI C320I does not support IPv6), ARP
ONVIF Yes
API Open Network Video Interface (Profile S)
Security Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication
Simultaneous Live View 3 Main Streams & 3 Sub-Streams
Cloud Yes
Client VIGI App, VIGI Security Manager, VIGI NVR, Web
Web Browser
• Google Chrome® 57 and above
• Firefox® 52 and above
• Safari® 11 and above
• Microsoft® Edge 91 and above
Alarm and Event Management
Smart Event
• Human & Vehicle Classification
• Intrusion Detection
• Line-Crossing Detection
• Region Entering Detection
• Region Exiting Detection
• Object Abandoned/Removal Detection
• Abnormal Sound Detection
• People Detection
• Vehicle Detection
Basic Event
• Motion Detection
• Video Tampering Detection
• Exception ( Illegal Login)
Alarm Linkage Message Push
Linkage Method N/A
Output Notification Message Push
Interface
Network Interface 1 RJ45 10/100M Self-Adaptive Ethernet Port
Alarm N/A
Reset Button N/A
Power DC Power Port (VIGI C320I does not have DC power port)
On-board Storage N/A
Built-in Microphone Yes; Records Anything Going on within a 15-ft Radius of the Camera
Built-in Speaker N/A
Audio N/A
General
Operating Temperature -30–60 °C
Power Supply PoE (802.3af/at, class 0)
12V DC ± 5%, 5.5mm
Coaxial Power Plug
PoE (802.3af/at, class 0)
12V DC ± 5%, 5.5mm
Coaxial Power Plug
PoE (802.3af/at, class 0)
Power Consumption PoE: class 0
12V DC: Max 5W
PoE: class 0
12V DC: Max 5W
PoE: class 0
Ingression Protection IP67
Material Plastic
Product Dimensions 78.5 × 188.03 × 71.55 mm (3.09 × 7.40 × 2.82 in)
Certification CE/BSMI/VCCI/ONVIF
