Camera
Image Sensor: 2MP CMOS Image Sensor
Signal System: PAL/NTSC
Effective Pixels: 1920(H)*1080(V)
Shutter Time: 1/25(1/30) s to 1/50,000 s
Lens Mount: M12
Adjustment Range: Pan: 0° to 360°, Tilt: 0° to 180°, Rotate: 0° to 360°
Day& Night: IR cut filter with auto switch
Wide Dynamic Range: 120dB
Video Frame Rate: 1080p@25fps/1080p@30fps
Synchronization: Internal Synchronization
Menu
D/N Mode: Auto / Color / B/W
Auto White Balance: Auto / Manual
BLC: Support
AGC: Support
Language: English/Chinese
General
Operating Conditions: -40 °C - 60 °C (-40 °F - 140 °F)
Humidity 90% or less (non-condensing)
Power Supply: 12 VDC ±25% *You are recommended to use one power adapter to supply the power for one camera.
Weather Proof: IP67
IR Range: Up to 60m
Communication : Up the coax
Protocol: HIKVISION-C(Coaxitron)
Dimension: 81.6 mm × 86.7 mm × 226 mm (3.2" × 3.4" × 8.9")
Weight: Approx. 560 g (1.23 lb.)
