Camera de supreaveghere 8 Mp, IP AcuSense DarkFighter HIKVISION DS-2CD3686G2-IZS 2.7-13.5mm (H)/eF

HikVision
HikVision
Cumpara de minim 500 lei pentru transport gratuit
Stoc 10
Cod produs - SKU DS-2CD3686G2-IZS(H)/eF2.7-13.5
Disponibil in stoc
Cere oferta de pret
Adauga la Favorite
Cum te putem ajuta?
Suna-ne: 0761.40.40.40 (Luni - Vineri: 08:30 - 17:30)
Trimite-ne un mesaj

Descriere

Tehnologia CMOS

Utilizata si in senzorii de imagine al camerelor Hikvision, tehnologia CMOS ajuta la captarea imaginilor la o calitate superioara. Printre caracteristicile importante ale dispozitivelor CMOS sunt imunitatea ridicata la zgomot si consum redus de energie.

Modalitatea foarte usoara de configurare a echipamentului permite vizualizarea chiar si de la distanta a camerelor. Aplicatia Hik-Connect va pune la dispozitie, printr-o simpla scanare a codului QR posibilitatea de a monitoriza zona dorita, oricand si oriunde


Functia  AcuSense filtreaza si elimina alarmele false (pasari, frunze, ploaie, lumina) cu o acuratete de peste 90%.

SD card

Scapa de grija instalatiilor complexe , de amalgamul de cabluri si echipamente grele si costisitoare, deoarece acum poti inregistra si stoca  imaginile pe propriul card SD pe care il conectezi direct la camera.

IP 66

Nivelul de protectie asigurat de carcasa camerei impotriva accesului la componentele interne, a corpurilor solide sau a patrunderii apei. IP 66 indica un grad superior de protectie asupra factorilor externi si ofera protectie impotriva efectului de imersie, intre 15 cm si 1 m

          • Camera
          • Image Sensor1/1.8" Progressive Scan CMOS
          • Max. Resolution3840 × 2160
          • Min. IlluminationColor: 0.003 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR
          • Shutter Time1/3 s to 1/100,000 s
          • Day & NightIR cut filter
          • Angle AdjustmentPan: 0° to 355°,tilt: 0° to 90°,rotate: 0° to 360°
          • Lens
          • Lens TypeVarifocal lens, motorized lens, 2.7 to 13.5 mm and 7 to 35 mm optional
          • Focal Length & FOV

            2.7 to 13.5 mm: horizontal FOV 108° to 46°, vertical FOV 58° to 26°, diagonal FOV 127° to 52°

            7 to 35 mm: horizontal FOV 42° to 15°, vertical FOV 23° to 9°, diagonal FOV 49° to 17°

          • Lens Mount2.7 to 13.5 mm: Ø14; 7 to 35 mm: Integrated
          • FocusAuto,Semi-auto,Manual
          • Iris TypeAuto-iris
          • ApertureF1.6
          • DORI
          • DORI

            2.7 to 13.5 mm: D: 86 to 192 m, O: 34 to 76 m, R: 17 to 38 m, I: 8 to 19 m

            7 to 35 mm: D: 218 to 580 m, O: 86 to 230 m, R: 43 to 116 m, I: 21 to 58 m

          • Illuminator
          • Supplement Light TypeIR
          • Supplement Light Range2.7 to 13.5 mm: up to 60 m; 7 to 35 mm: up to 80 m
          • Smart Supplement LightYes
          • IR Wavelength850 nm
          • HEOP
          • Open Resources

            Memory: 40 MB,

            Smart RAM: 350 MB,

            eMMC: 2 GB

          • Computing Power1.5 TOPS
          • Open CapabilityHEOP 2.0 OpendevSDK
          • Deep Learning StructureCaffe,PyTorch,TensorFlow,PaddlePaddle,ONNX
          • Programming LanguageC,C++
          • Video
          • Main Stream

            50 Hz:

            25 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)

            60 Hz:

            24 fps (3840 × 2160)

            30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)

          • Sub-Stream

            50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)

            60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)

          • Third Stream

            50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)

            60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)

          • Fourth Stream

            50 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360)

            60 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360)

          • Video Compression

            Main stream: H.265/H.264/H.264+/H.265+,

            Sub-stream: H.265/H.264/MJPEG,

            Third stream: H.265/H.264,

            Fourth stream: H.265/H.264/MJPEG,

            *Third stream and fourth stream are supported under certain settings.

          • Video Bit Rate32 Kbps to 16 Mbps
          • H.264 TypeBaseline Profile,Main Profile,High Profile
          • H.265 TypeMain Profile
          • Bit Rate ControlCBR,VBR
          • Scalable Video Coding (SVC)H.264 and H.265 encoding
          • Region of Interest (ROI)5 fixed regions for main stream and sub-stream
          • Target CroppingYes
          • Audio
          • Audio CompressionG.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
          • Audio TypeMono sound
          • Audio Bit Rate64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
          • Audio Sampling Rate8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
          • Environment Noise FilteringYes
          • Network
          • ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SFTP, ARP, SNMP, WebSocket, WebSockets, SRTP
          • Simultaneous Live ViewUp to 6 channels
          • APIONVIF (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP
          • User/Host

            Up to 32 users

            3 user levels: administrator, operator, and user

          • SecurityPassword protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.1/1.2/1.3, host authentication (MAC address)
          • Network Storage

            NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR),

            Together with high-end Hikvision memory card, memory card encryption and health detection are supported.

          • ClientiVMS-4200,Hik-Connect,Hik-Central
          • Web Browser

            Plug-in required live view: IE 10, IE 11,

            Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+,

            Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+

          • Image
          • Image Parameters SwitchYes
          • Image SettingsRotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
          • Day/Night SwitchDay,Night,Auto,Schedule
          • Wide Dynamic Range (WDR)120 dB
          • Image EnhancementBLC,HLC,3D DNR,Defog
          • SNR≥ 52 dB
          • Privacy Mask4 programmable polygon privacy masks
          • Interface
          • Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
          • On-Board StorageBuilt-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
          • Audio

            1 input (line in), 3.5 mm connector, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium

            1 output (line out), 3.5 mm connector, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium

          • Alarm1 input, 1 output (max. 24 VDC/24 VAC, 1 A)
          • Reset KeyYes
          • Event
          • Basic EventMotion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception
          • Smart Eventscene change detection,audio exception detection,defocus detection, unattended baggage detection,object removal detection
          • LinkageUpload to FTP/NAS/memory card,notify surveillance center,send email,trigger recording,trigger capture,trigger alarm output,audible warning
          • Deep Learning Function
          • Perimeter Protection

            Line crossing, intrusion, region entrance, region exiting

            Support alarm triggering by specified target types (human and vehicle)

          • Face CaptureYes
          • People CountingYes
          • General
          • Power

            12 VDC ± 25%, 1.08 A, max. 13 W,two-core terminal block,reverse polarity protection,

            PoE: IEEE 802.3at, Class 4, max. 15 W

          • MaterialAluminum alloy body
          • DimensionØ144 mm × 332.1 mm (Ø5.7" × 13.1")
          • Package Dimension385 mm × 190 mm × 180 mm (15.2" × 7.5" × 7.1")
          • WeightApprox. 1550 g (3.4 lb.)
          • With Package WeightApprox. 2596 g (5.7 lb.)
          • Storage Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
          • Startup and Operating Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
          • General FunctionHeartbeat,anti-banding,mirror,flash log,password reset via email,pixel counter
          • Language33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
          • Approval
          • EMC


            CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014,

            IC: ICES-003: Issue 7,

            KC: KN32: 2015, KN35: 2015

          • Safety

            UL: UL 62368-1,

            CB: IEC 62368-1: 2014+A11,

            CE-LVD: EN 62368-1: 2014/A11: 2017,

            BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005

          • Environment

            CE-RoHS: 2011/65/EU,

            Reach: Regulation (EC) No 1907/2006

          • ProtectionIP66: IEC 60529-2013,IK10: IEC 62262:2002

        Detalii

        SKU
        DS-2CD3686G2-IZS(H)/eF2.7-13.5
        Categorii
        Camere IP bullet
        Brand
        HikVision
        SD Card
        Da
        Producator
        HikVision
        Rezolutie
        8 MP (4K)
        Distanta iluminare IR
        40 - 60 m
        Audio
        Intrare/Iesire audio
        Lentila
        Zoom motorizat
        Interior/Exterior
        Exterior
        Tip carcasa / camera
        Bullet
        Tehnologie
        IP
        Fisa tehnica
        datasheet_of_ds_2cd3686g2_izs.pdf
