Camera de supreaveghere 4 Mp, IP DeepinView, ANPR, HIKVISION iDS-2CD7A45G0/P-IZHSY

Descriere

Tehnologia CMOS

Utilizata si in senzorii de imagine al camerelor Hikvision, tehnologia CMOS ajuta la captarea imaginilor la o calitate superioara. Printre caracteristicile importante ale dispozitivelor CMOS sunt imunitatea ridicata la zgomot si consum redus de energie.

Modalitatea foarte usoara de configurare a echipamentului permite vizualizarea chiar si de la distanta a camerelor. Aplicatia Hik-Connect va pune la dispozitie, printr-o simpla scanare a codului QR posibilitatea de a monitoriza zona dorita, oricand si oriunde

Functia  AcuSense filtreaza si elimina alarmele false (pasari, frunze, ploaie, lumina) cu o acuratete de peste 90%.

SD card

Scapa de grija instalatiilor complexe , de amalgamul de cabluri si echipamente grele si costisitoare, deoarece acum poti inregistra si stoca  imaginile pe propriul card SD pe care il conectezi direct la camera.

IP 67

Nivelul de protectie asigurat de carcasa camerei impotriva accesului la componentele interne, a corpurilor solide sau a patrunderii apei. IP 66 indica un grad superior de protectie asupra factorilor externi si ofera protectie impotriva efectului de imersie, intre 15 cm si 1 m

• • Camera
  • Image Sensor1/1.8″ progressive scan CMOS
  • Max. Resolution2688 × 1520
  • Min. IlluminationColor: 0.0005 Lux @ (F1.2, AGC ON),B/W: 0.0001 Lux @ (F1.2, AGC ON), 0 Lux with IR
  • Shutter Time1/50 s to 1/40,000 s
  • Day & NightIR cut filter
  • Lens
  • Focal Length & FOV




    2.8-12mm : Horizontal: 113.5° to 39°, Vertical: 58.4° to 22.7°, Diagonal: 141.3° to 44.3°,

    8-32mm : Horizontal: 41.9° to 15.1°°, Vertical: 22.9° to 8.64°, Diagonal: 48.8° to 17.3°,

    10-50mm: Horizontal: 32.2° to 7.8°°, Vertical: 18.1° to 4.4°, Diagonal: 37.1° to 8.95°

  • FocusAuto
  • Iris TypeDC-IRIS
  • Aperture

    2.8-12mm : F1.38,

    8-32mm : F1.7,

    10-50mm : F1.7

  • Illuminator
  • Built-in Supplement Light TypeIR light
  • Supplement Light Number3
  • Built-in Supplement Light RangeUp to 50 m
  • IR Wavelength850 nm
  • Video
  • Main Stream




    50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720, 704 × 576, 352 × 288)

    60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720, 704 × 576, 352 × 288)

  • Sub-Stream




    50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 352 × 288)

    60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 576, 352 × 288)

  • Third Stream




    50 Hz: 25 fps (1280 × 720, 704 × 576, 352 × 288)

    60 Hz: 30 fps (1280 × 720, 704 × 576, 352 × 288)

  • Video Compression

    H.264 and H.265 encoding

    Main stream: H.265/H.264/MJPEG

    Sub-stream: H.265/H.264/MJPEG

  • Video Bit Rate32 Kbps to 16 Mbps
  • H.264 TypeBaseline profile/Main profile/High profile
  • H.265 TypeMain profile
  • Audio
  • Audio CompressionG.711/G.722.1
  • Audio Bit Rate8Kbps (G.711) /16Kbps (G.722.1)
  • Network
  • ProtocolsTCP/IP,ICMP,HTTP,HTTPS,FTP,SFTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,NTP,SMTP,SNMP,IGMP,QoS,IPv4/IPv6,UDP,SSL/TLS,ISUP,ARP,802.1X
  • Simultaneous Live ViewUp to 6 channels
  • APIISAPI,SDK,ISUP,ONVIF (PROFILE S, PROFILE G, PROFILE T, PROFILE M)
  • User/Host

    Up to 32 users

    3 user levels: administrator, operator, and user

  • SecurityPassword protection,Complicated password,HTTPS encryption,802.1X authentication (EAP-PEAP, EAP-LEAP, EAP-MD5),Watermark,IP address filter,Basic and digest authentication for HTTP/HTTPS,WSSE and digest authentication for ONVIF,RTP/RTSP over HTTPS,Control timeout settings,Security audit log,TLS 1.2, 1.3,Host authentication (MAC address)
  • Network StorageMicro SD/TF card (512 GB), local storage and CVR, NVR, ANR
  • ClientHik-Central Master,Hik-Central Pro
  • Web BrowserChrome V61+, IE9 to IE11, Firefox V41+, Edge
  • Wireless (Mobile Communication)
  • Frequency

    /G model:

    LTE FDD: Band 1,2,3,4,5,7,8,12,17,28,66

    LTE TDD: Band 38,40

    WCDMA/HSPA+: Band 1,2,3,4,5,8

    GSM/GPRS/EDGE: 850/900/1800/1900MHz

  • Standard/G model: LTE FDD/LTE TDD/WCDMA/HSPA+/GSM/GPRS/EDGE
  • SIM Card Type




    /G model: Micro SIM

  • Image
  • Image SettingsSaturation,Brightness,Contrast,Gain,Sharpness,White balance,AGC,Adjustable by client software or web browser.
  • Day/Night SwitchAuto/Scheduled/Manual
  • Wide Dynamic Range (WDR)140 dB
  • Image EnhancementBLC, 3D DNR
  • Supplement Detection (Satellite Positioning)
  • Satellite Positioning




    /G model: GPS

  • Interface
  • Ethernet Interface1 RJ45 10M/100M/1000M Ethernet interface
  • On-Board StorageBuilt-in memory card slot, supporting microSD/SDHC/SDXC card, up to 512GB
  • AudioSupported
  • Alarm1 input interface, 1 output interface, 2 relays
  • RS-4851 RS-485 interface
  • Wiegand1 Wiegand (CardID 26bit, SHA-1 26bit, Hik 34bit)
  • Event
  • Basic EventHDD Error, Network Disconnected, IP Address Conflicted, Vehicle Detector Exception, Traffic Light Detector Exception
  • Road Traffic and Vehicle Detection
  • CoverageUp to 3 lane(s)
  • Smart Function

    Helmet Detection, Manned Non-Motor

    Traffic flow detection：average speed, traffic flow, queuing length, and traffic status

    Incident detection: congestion, stopped vehicle, lane change, wrong-way driving, speeding, low-speed driving

  • LPR Countries/Regions

    Middle East: The United Arab Emirates (Abu Dhabi, Ajman, Dubai, Fujairah, Ras Al Khaimah, Sharjah and Umm Al Quwain), Qatar, Iraq, Egypt, Jordan, Kuwait, Saudi Arabia, Pakistan, Oman, Lebanon, Bahrain,

    Africa: Nigeria, Kenya, Ivory Coast , South Africa, Tanzania, Mauritius, Morocco, Tunisia, Sierra Leone, Zambia, Ghana, Zimbabwe, Uganda, Angola, Ethiopia, Senegal, Algeria,

    Asia-Pacific: Australia, New Zealand, Indonesia, Malaysia, Singapore, South Korea, Thailand, Vietnam, the Philippines, Hong Kong, Macao, Taiwan, Myanmar, India, Mongolia, Cambodia, Laos, Bangladesh, Nepal, Sri Lanka,

    America: Canada, Argentina, Chile, Paraguay, Uruguay, El Salvador, Bolivia, Colombia, Brazil, Ecuador, Peru, Mexico, Panama, Costa Rica, Trinidad and Tobago, the Dominican Republic, Guatemala,

    Europe: Turkey, Croatia, Slovakia, Czech Republic, Bulgaria, the Republic of North Macedonia, Hungary, Greece, Poland, France, Netherlands, Switzerland, Spain, the UK, Ireland, Germany, Italy, Austria, Israel, Palestinian, Belgium, Luxembourg, Albania, Kosovo, Serbia, Romania, Montenegro, Denmark, Finland, Sweden, Slovenia, Portugal, Malta, Cyprus, Iceland, Liechtenstein, Bosnia and Herzegovina,

    Russian-Speaking Regions: Azerbaijan, Belarus, Kazakhstan, Lithuania, Georgia, Estonia, Latvia, Russia, Ukraine, Moldova, Uzbekistan, Kyrgyzstan, Armenia, Turkmenistan, Tajikistan

  • Accuracy (Under recommended installation and lighting conditions)

    Capture rate > 99%,

    Vehicle moving direction recognition accuracy > 98.5%,

    LPR accuracy > 98%,

    Mistaken capture rate < 2%

  • No License Plate DetectionSupported
  • Motorcycle LPRSupported
  • Vehicle TypeCar,Van,Bus,Truck,Light Truck,SUV(MPV),Pickup,Motorcycle,Tricycle
  • Vehicle Color

    Red, yellow, green, blue, pink, purple, cyan, brown, white, grey, black

    Recognizable at daytime only.

  • Vehicle Manufacturer212 Manufacturers: AC SCHNITZER, AITO, APOLLO, Ashok Leyland, Audi, Aston Martin, Acura, Ankai, Ayvip, Alfa Romeo, Asiastar, Artega, ARCFOX, BAIC, Beiben Truck, BLUECAR, Bedford, Benz, BMW, BYD , Bufori, Buick, Bently, Brabus, Bugatti, Borgward, BONLUCK, Besturn, CADILLAC, Celis, Chevrolet, Citroen, Chery, Chrysler, Chang an, CNHTC, CHTC, Caterham, Conquest, C&C Trucks, CAMC, DAIHATSU, DMC, DS, Dacia, Dongnan, Dodge, Dongwo, Denza, Dongfeng, Daewoo, Dima, Denway, DORCEN, Eicher, Emgrand, Equss, EXEED, Ford, FORO, Fornasari, Ferrari, Fuqi, Fiat, Fisker, FQT Motor, Foton, FAW, FORLAND, FUSO, Force Motors, Fxauto, Faralli Mazzanti, GAC, Great Wall, GMC, Geely, Geometry, Hyundai, HENNESSEY, HINO, Honda, Haima, Haval, Hongqi, Isuzu, Infiniti, Iveco, IAT, IM, JAC, JBC, JEEP, Jaguar, JMC, JETOUR, JETTA, Joylong ,Koenigsegg, KIA , Kia-Borrego, King Long, Kama, KTM, LEVC, Lexus, Land Rover, Lincoln, Lamborghini, Lotus, Luxgen, Levdeo, Leopaard, Lynk & Co , Lada, Leading Ideal, LEAPMOTOR, LUMMA, Lorinser, Land Wind, MAN Trucks , MAXUS, MG, MINI, Mahindra, Mitsuoka, Maserati, Meiya , McLaren, Maybach, Mazda, Morgan, Mitsubishi, Mustang, Marvel R, Maple, MANSORY, Modern, NOMA, Nissan, Norinco, Neoplan, NIO, NETA, Opel, Ora, Oushang, Perodua, Porsche, Peugeot, PGO, Proton, Pagani, Polestar, POCCO, Qoros, RAM, Rolls-Royce, Renault, Roewe, Rohens, Ranz, Ruilan, Radar, Renault Samsung, SAAB, SCANIA , SCION, SMART, SML ISUZU, Suzuki, SAIC Datong, Subaru, Skoda, Startek, Soyat, Seat , SWM, Sany, SsangYong, Sojen, Silver, SATE, SOL, Skyworth, SGMW, SITECH DEV, TATA, Tankar, Tesla, Trumpchi, Techart, Toyota, UD, UAES, Volkswagen, VINFAST, Venucia, Volvo, VOYAH, VeiculoLongo, Weltmeister , XCMG, Xinyuan, XPENG, Yutong, YAMAHA, Zhonghua, Zotye, Zhinuo, ZEEKR, Zenvo
  • Capture Speed Range5 to 120 km/h
  • Blocklist and AllowlistMax. 50000 records
  • General
  • Operating SystemLinux
  • Power

    DC 12 V to 24 V, 1.25 A, max. 15 W, two-core terminal block,

    PoE: 802.3at, Type 2, Class 4, max. 15 W

  • MaterialAluminum alloy
  • Dimension428.5 mm × 120 mm × 132.8 mm (16.9" × 4.72" × 5.2") (L × W × H)
  • Package Dimension595 mm × 259 mm × 193 mm (23.4" × 10.2" × 7.6") (L × W × H)
  • WeightApprox. 2.975 kg (6.56 lb.)
  • With Package WeightApprox. 4.385 kg (9.67 lb.)
  • Operating Condition-30 °C to 70 °C (-22 °F to 158 °F). Humidity 95% or less (non-condensing)
  • Storage Condition-30 °C to 70 °C (-22 °F to 158 °F). Humidity 95% or less (non-condensing)
  • General FunctionOne-key reset, three streams, heartbeat, password protection, watermark
  • Language8 languages: English, Thai, Croatian, Korean, Russian, Traditional Chinese, Ukrainian, Spanish
  • Approval
  • RF




    EN 301 489-1 V2.2.3, EN 301 489-3 V2.3.2, EN 301 489-19 V2.2.1, EN 301 489-52 V1.2.1, EN 301 511 V12.5.1, EN 301 908-2 V13.1.1, EN 301 908-1 V15.2.1, EN 301 908-13 V13.2.1, EN 303 413 V1.2.1, EN IEC 62311:2020

  • EMCCE-EMC: EN 55032: 2015/A11:2020+A1:2020, EN IEC61000-3-2: 2019/A1:2021, EN 61000-3-3: 2013+A1:2019/A2:2021, EN 50130-4: 2011 +A1: 2014
  • SafetyCB: IEC 62368-1: 2014+A11,CB: IEC 62368-1: 2018+A11,CE-LVD: EN 62368-1: 2014/A11: 2017
  • EnvironmentCE-RoHS: 2011/65/EU,WEEE: 2012/19/EU,Reach: Regulation (EC) No 1907/2006
  • ProtectionIK10: IEC 62262:2002,IP67: IEC 60529-2013
  • Anti-Corrosion Protection-Y: NEMA 4X (NEMA 250-2018)
