Bridge point to point HikVision Wireless de exterior pana la 15km transmisie DS-3WF03C

Descriere

Wi-Fi

Wi-Fi sau WiFi este o tehnologie , care permite dispozitivelor electronice sa se conecteze la o retea fara a fi nevoie de fir.Reteaua folosind in general  2,4 gigahertzi UHF  si 5 gigahertzi SHF ISM benzi radio

• Wireless
• StandardIEEE802.11 a/n
• Operating Frequency5745~5825 MHz (Note: Available channel may vary depending on local regulations)
• Output Power27 dBm (Note: Maximum output power may vary in different channels depending on local regulations)
• Receive Sensitivity-72 dBm@54 Mbps, -85 dBm@MCS0
• AntennaBuilt-in antenna: gain 15 dBi, H: 40°, V: 15°
• Wireless Link Rate300 Mbps
• Maximum Power Consumption10.1 W

• Hardware
• Power Supply24 V/0.5 A Passive PoE
• Interface10/100 Mbps Base-TX × 2
• Operating Humidity5%~95%RH non-condensing
• Passive PoE Power Supply DistanceUp to 60 meters with Cat.5e or better
• Operating Temperature-30°C ~75°C (-22°F ~167°F)
• Storage Temperature-40°C ~85°C (-40°F ~185°F)
• Dimensions270mm × 41mm × 88mm (10.6×1.6×3.5 in)
• LED IndicatorPower indicator / LAN / WLAN / signal strength indicator
• Net Weight283.5g
• Gross Weight708.0g

• Software
• EncryptionWPA-PSK/WPA2-PSK
• SecurityIP/MAC filter, SSID hidden
• Network ProtocolTCP/UDP/ARP/ICMP/HTTP/NTP
• Configuration ManagementSupport web configuration, Support SNMP management
• Bandwidth20 M/40 MHz
• Management And LogsNTP, Syslog, SNMP
• Firmware UpdateSupport update firmware by Web page
